Spigot System

Published:2015-06-05 Views:1661

Construction

Sizes:	ID80mm to ID300mm
Inner Liner (Flue):	SUS316L series stainless steel 0.5mm thickness
Outer Casing:	SUS304 series stainless steel 0.5mm thickness
Insulation:	25mm space between the inner/outer walls is packed with ceramic fiber insulation to provide superior insulating qualities in a slim-line design.
Airspace Clearance to Combustibles:	50mm

Standard:

CE approval

Designation 1 DN (100-300) – T600 – N1 – D – V2 – L50050 – O50

Designation 2 DN (100-300) – T600 – N1 – D – V2 – L50050 – G75

Designation 3 DN (100-150) – T450 – N1 – D – V2 – L50050 – G50

Designation 4 DN (100-150) – T450 – N1 – D – Vm – L50045 – G50

Designation 5 DN (100-150) – T450 – N1 – D – Vm – L20040 – G50
